M210
M210 有源主扩模块采用两分频设计，配备两只轻量化纯中频 10″钕磁驱动器（号筒负载），与四只 3″钕磁压缩驱动器同轴安装，并搭载创新的可调波导系统。
M210 采用定制化 15 mm 桦木与杨木复合夹板箱体，其圆角设计有效提升抗冲击性能，整机重量控制在 53 kg/117 lbs，同时实现 148 dB 峰值声压级。中频号筒可确保最大的辐射表面级和高效率。
独特的可调节高频波导设计用于调节垂直指向性。该系统采用连续渐变水平指向性设计，通过可选配的磁吸式波导法兰从 120°（底部）精准调节至 60°（顶部）。
主要特点
- Alpha+ 系统主扩模块非常强大（峰值声压级 148 dB）
- 轻量化 (53 kg / 117 lbs) 设计，采用 15 mm 定制桦木与杨木复合弯曲胶合板
- 独特的可调节高频波导设计，用于调节垂直指向性
- 该系统采用连续渐变水平指向性设计，通过可选配的磁吸式波导法兰从 120°（底部）精准调节至 60°（顶部）
- 中频号筒可确保最大的辐射表面级和高效率
产品参数
| With NEXO Processing | |
| Frequency Response @-6 dB | 160 Hz to 20 kHz |
| Peak SPL@1m | 148 dB Peak |
| Operating Voltage | 45 Vrms (150 Vpeak) |
| Crossover Frequency | 500 Hz to 1500 Hz overlap, optimized with proprietary software NEXO Polar Combiner |
| Vertical Dispersion | Adjustable (-20°/+20° Default mode) or (-20°/+0° Long Throw mode) |
| Horizontal Dispersion | 120° (Bottom) to 60° (Top) continuously |
| Nominal Impedance | 4 Ohms + 4 Ohms |
外观特征
| MF Components | 2 x High-efficiency pure medium neodymium 10” 8 Ohms |
| HF Components | 4 x Neodymium 3“ voice coil 1.4” throat driver on a BEA/FEA optimized Wavesource |
| Connectors | 2 x NL4, 4 poles connectors |
| Rigging points | 2 x universal accessory fit (on each side) + 1 x universal accessory fit on the back |
| Material | Custom made bent plywood of baltic birch and poplar |
| Finish | Black or White structural paint |
| Front Finish | Magnelis® Steel front grille |
| Height x Width x Depth | 598mm x 755mm x 632 mm (23.5” x 29.7” x 24.9”) |
| Weight: Net | 53 kg (117 lbs) |
| Operating temperature range | 0°C - 40 °C (32° F - 104° F) |
| Storage temperature range | -20 °C - 60 °C (-4 ° F - 140° F) |
| System Operation | |
| Recommended powering solution | NXAMP4x4mk2 Powered TDcontroller: Up to 2 x M210 (MF/HF) on 2 x channels |
| Optional powering solution | NXAMP4x1mk2 Powered TDcontroller (Bridged): Up to 2 x M210 (MF/HF) per amplifier |
| NXAMP4x2mk2 Powered TDcontroller: 1 x M210 (MF/HF) on 2 x channels |
